Single-phase capacitor MONO LONG LIFE
Referencia: 416532100
Networks with low harmonic content <60% THDi.
Lifespan: >110,000. Maximum input current: 200ln. Maximum allowable overload: 4xln.
These capacitors are used for power factor correction. They do not contain toxic substances (PCB-free), made of self-healing polypropylene. Equipped with an overpressure device.
Frequency: 50/60 Hz
Tolerance: -5%+ 10%
Maximum altitude: 2000m
Continuous service
Protection degree: IP00
Material: aluminum
Fixing: M12 screw
Discharge resistor: not included
Test voltage on terminals: 2.15Un x 2s
Thermal class: -25/D (55ºC)
Terminal connection:
• 1.67~6.66kVAr: double faston terminal
• 8.33~10kVAr: M5 screw
Standards: IEC 831-1/2
