EPB63MDC Magnetothermal automatic switch for Direct Current. Industrial. Cutting power: 6kA
Referencia: EPB63MDC1C01
• Operating voltage: 250/500/750/1000VDC
• Minimum operating voltage: 12VDC
• International standard EN/IEC60947-2
• Local status signaling
• Circuit marker window
• Terminal connection for copper cables:
• Gauge =25A: flexible =16mm2 and rigid =25mm2
• Caliber 32÷63A: flexible =25mm2 and rigid =35mm2
• Dimensions: 1 module per pole (18mm)
• Allows the coupling of accessories and electrical auxiliaries
• Suitable for sectioning
• Working temperature: -5÷400C
