CL Ammeter clamp for solar installations, measurements in DC and AC
Referencia: CL30-1NZ0000000000
General characteristics:
• Special jaw with rotation up to 360o
• IEC6F22 alkaline battery
Mechanical characteristics:
• Size (L x H x D): 270x70x90mm
• Weight: 600g
• Jaw opening: 51mm
Environmental characteristics:
• Operating temperature: -10÷55oC
• Storage temperature: -20÷70oC
• Relative humidity: 0÷90% without condensation
• Degree of protection:
• IP50 in housing
• IP20 on terminals
Rules:
• Safety: IEC61010-1-2010
CAT IV 600V
CAT III 1000V
• IP water and dust: IEC60529
• Emission: IEC61326:2012 class B
• Immunity: IEC61326:2012, IEC61000-4-2, IEC61000-4-3
• Pollution degree: 2
